USB to RS485 Bidirectional Converter
€14,93 /€12,34 excl. VAT
Available via backorder
- Free shipping from € 74,95 NL. (€ 99,95 BE / DE)
- Ordered before 16:00 tomorrow Indoor
- Express ordered before 10:30 am tonight at home*
- 14 days free return *
- Can also be collected from us in Leusden!
Description USB to RS485 Bidirectional Converter
The USB to RS485 Bidirectional Converter is a high-quality industrial tool. It contains an original FT232RL chip. This makes the device fast, stable and reliable. The converter is compact. This makes it easy to use.
The protection circuits are a unique feature. They include lightning protection, a resettable fuse, ESD protection, and a TVS diode. These functions protect against voltage spikes and electrostatic discharges.
The communication via USB to RS485 is efficient. The converter has three LED indicators. These show the status of power and data transfer. Build quality focuses on durability and reliability in demanding environments.
Features USB to RS485 Converter
- USB to RS485 communication
- Original FT232RL and SP485EEN, communicating quickly, stable and reliable, better compatibility;
- Onboard TVS (Transient Voltage Suppressor), effectively suppress surge voltage and transient surge voltage in the circuit, lightning resistant and anti-electrostatic
- Onboard resettable fuse and protection diodes, provides current/voltage stable outputs, provides overcurrent/overvoltage resistance, improves shock resistance
- 3 LEDs to indicate power and transceiver status
Specifications USB to RS485 Converter
- Product type: industrial converter
- Baud rate: 300-921600bps
- Host port: USB
- Device port: RS485
- USB:
- Operating voltage: 5V
- Connector: USB-A
- Protection: 200mA self-recovery fuse, ESD protection
- Transmission distance: about 5m
- RS485:
- Connector: screw terminal
- Pins: A+, B-, GND
- Direction control: hardware automatic control
- Protection: 600W lightningproof and surge suppress, 15KV ESD protection (onboard 120R balancing resistor)
- Transmission distance: about 1200m (low rate)
- Transmission mode: point-to-multipoints (up to 32 nodes, it is recommended to use repeaters for 16 nodes or more)
- LED indicators:
- PWR: red power indicator, lights up when there is USB connection and voltage is detected
- TXD: red TX indicator, lights up when the USB port sends data
- RXD: red RX indicator, lights up when the device ports send data back
- operating environment:
- Temperature: -15℃ ~ 70℃
- Humidity: 5%RH ~ 95%RH
- Operating system: Mac, Linux, Android, WinCE, Windows 11 / 10 / 8.1 / 8 / 7 / XP
