Breadboards

Are you looking for a Breadboard as a tool for designing and testing circuits? In our webshop we have different types of breadboards with a variety of tie points. Our Breadboards are often used in combination with Arduino, Raspberry Pi and ESP products. View our assortment of Breadboards here.

12 producten gevonden

Sorteren op:

What is a Breadboard?

A breadboard is an easy way to quickly set up, test, and modify circuits. The advantage of a breadboard is that you don’t have to solder wires and components to create a circuit while using the breadboard. You simply slide components in and out of the spring-loaded holes. This allows you to change your circuit design at any time without hassle.

What is a breadboard made of?

A breadboard consists of a series of conductive metal clips in a white ABS plastic casing. Each clip is insulated with another clip and there are a number of holes on the side of the plastic casing. The boards are numbered and arranged in a certain way. A typical Breadboard layout consists of two types of regions also called strips. Bus strips and socket strips. Bus strips are usually used to provide power to the circuit. It consists of two columns, one for power supply and one for ground. Socket strips are used to hold the components in a circuit. Generally it consists of two sections with 5 rows and 64 columns each. Each column is electrically connected from the inside.
