DTOF Laser Lidar Sensor STL27L
€169,94 /€140,45 excl. VAT
Out of stock
Would you like to be notified when this product is back in stock?
Would you like to be notified when this product is back in stock?
- Free shipping from € 74,95 NL. (€ 99,95 BE / DE)
- Ordered before 16:00 tomorrow Indoor
- Express ordered before 10:30 am tonight at home*
- 14 days free return *
- Can also be collected from us in Leusden!
Description DTOF Laser Lidar Sensor STL27L
This is the DTOF Laser Lidar Sensor STL27L from Waveshare. This lidar system uses TOF (Time-Of-Flight) Ranging Technology. This provides accurate measurements over long distances, up to 25 meters. It guarantees a measuring accuracy of ±20mm within a range of 8 meters. Which is essential for countless applications such as robotics, autonomous navigation and obstacle detection. It has a scan rate of 10Hz and a high measurement frequency of 21600Hz. This minimizes navigation blind spots and maximizes coverage. In addition, the multi-echo detection technology makes it possible to detect glass walls. This prevents collisions and increases safety. It has low power consumption and a long service life of more than 10.000 hours. Which ensures long-term reliability.
Features DTOF Laser Lidar Sensor STL27L
-
Measuring distance: Varies from 0.03 to 25 meters (at a reflectivity of 80.6%)
-
Average margin of error: Only ±15mm to ±30mm depending on distance
-
Scan speed: 10Hz for real-time data
-
Scan angle: Full 360° coverage
-
Measuring frequency: 21600Hz for accurate measurements
-
Wavelength: Between 895 and 915 nm
-
Communication interface: UART@921600 for easy connectivity
-
Ambient light tolerance: Up to 60 KLux
-
Power supply: Operates on 4.5~5V (Typ 5V) with a low power consumption of only 1.45W
-
Operating temperature: Works smoothly between -10°C and 50°C
-
Lifespan: more than 10.000 hours
